Technical Specifications

Model AS6-US AS6-RW
PRODUCT INFORMATION
Input current type AC AC
Input voltage 90V – 140V 220V
Frequency 60Hz 50Hz/60Hz
Operational temperature range -30°C ~ 65°C -30°C ~ 65°C
-22°F ~ 149°F -22°F ~ 149°F
Dimensions 246 x 180 x 64 mm 246 x 180 x 64 mm
9.65 x 7.09 x 2.52 in 9.65 x 7.09 x 2.52 in
Weight 2.24kg / 4.94lb 2.24kg / 4.94lb
Power cord length 1.0m / 3.28ft 1.0m / 3.28ft
PORT INFORMATION
Number of ports 6 6
Port output voltage 24V AC 24V AC
Connector type Universal pool valve actuator connector (JST-03NR-E4K) Universal pool valve actuator connector (JST-03NR-E4K)
CONNECTIVITY & SMART FEATURES
Wi-Fi Yes Yes
Bluetooth Yes Yes
App control Tuya Smart Tuya Smart
  • The technical specifications listed on this website and other resources are subject to change without prior notice. Please check with your supplier or reseller for more detailed information.
  • Unless otherwise stated, all performance claims and pool size coverage are based on theoretical performance. Actual figures may vary in real-world situations. Please check with your supplier or reseller for more detailed information.
  • Brands and product names mentioned are trademarks of their respective companies.
  • Please check with your supplier or reseller for model, color and optional modules availability in your local area.
  • All illustrations and colors shown on this webpage are for illustrative purposes only.
